150 f / 200 f premium metal ceiling
150 F PREMIUM METAL CEILING
The P.R. FORTILAM 150F ceiling system features 150 mm X 17 x 0.50 mm panels that are roll formed from PVC wooden skin plates coated with 140-160 microns of polyvinylchloride on the front side. The metal ceiling systems utilize G.I sheets with a zinc coating of 150 GSM as per UNI EN 10346:2009. Light reflection adheres to ASTM E-1477-98 standards. Additionally, the material must pass corrosion tests for resistance to salt fog according to EN13523-8 and ASTM B117-16 for 300 hours. Fire safety is also paramount, with materials needing to pass the fire tests outlined in BIS 476 PART 6:1989+A 1:2009 & PART 7:1997, with raw materials compliant with EN13501-1:2019 A2S2D0. The acoustic ceiling panels are affixed to roll-formed carriers measuring 34.5 mm wide X 48 mm deep, made from 0.6mm G.I Coil, featuring cutouts and prongs to securely hold the panels in a 150 mm module at a maximum spacing of 1.7 m c/c without insulation and 1.5 m c/c with insulation. These carriers are suspended from the roof or truss using 4 mm diameter galvanized steel wire rod hangers or ceiling angles sized 24x24 mm x 0.5 mm at a maximum of 1.3 m c/c. Hangers are fastened to the roof with 'J' hooks and nylon inserts. Panels are pre-cut in lengths of up to 5 m to accommodate site dimensions or shop drawings. Edge profiles or wall angles measure 24 mm X 24 mm X 0.35 mm thick and are color-matched to the panels. Panels can be perforated with holes of either 2.5 mm or 1.8 mm in diameter. To enhance sound absorption, non-woven acoustic fleece will be applied to the back side of the perforated tiles, achieving an NRC rating of 0.7 (IS: 8225/ISO: 354/ASTM 423 C). All PVC coated materials must successfully pass scratch tests and pencil hardness tests as per ASTM D 3363-92a B.
